SR-B5-8017-T46W InGaAs Photodiode
(Replacement of G12181-005K)
SR-B5-8017-T46W is an InGaAs photodiode for near-infrared detection and replacement evaluation in defined industrial, medical-instrument, and research applications. It is designed as an alternative to the G12181-005K photodiode for near-infrared detection projects. Engineers should confirm spectral response, active area, package footprint, dark current, and circuit compatibility before replacement.
Applications
Specifications
| Technical Specifications | |
|---|---|
| Parameter | Rating |
| Bandwidth | 20.5 nm |
| Wavelength of Peak Sensitivity | 680 nm |
| Sensitivity range at 10% (λmin, λmax) | 800 – 1700 nm |
| Total Capacitance | 13.5 – 18 pF |
| Rise/Fall Time | 12/15 ns |
| Breakdown Voltage | 20 – 35 V |
| Dark Current | 1 – 10 nA |
| Shunt Resistance | 1.5 – 3.5 GΩ |
| Noise Equivalent Power | 8.5×10-14 w/√Hz |
| Specific Detectivity | 11×1012 w/Hz·cm·w-1 |
| Photocurrent at λ=1300nm | 2.3 μA |
Key Features / Advantages
Replacement for G12181-005K
The SR-B5-8017-T46W is an alternative for G12181-005K photodiode replacement evaluations. Key advantages include:
Why Choose Sartec
Product Line Link
Related Guides
Technical Support
When evaluating the SR-B5-8017-T46W as an alternative to the G12181-005K, Sartec Photoelectronics provides:
- Parameter and package compatibility review
- Sample support for circuit and system validation
- OEM supply for prototype and production requirements
- Datasheet and model-selection assistance
Contact Sartec Photoelectronics to request a datasheet, sample, or compatibility review.
Get a Quote / Request Model Confirmation
Tell us your target replacement model and application, and our engineers will recommend a suitable match for your requirements. Whether you’re looking to replace an existing component or seeking advice on the most suitable model for your specific application, we can review your application requirements. Our team reviews wavelength, package, circuit, and replacement requirements before suggesting a suitable option. Reach out today, and let us assist you in selecting a suitable component for your project!
G12181-005K equivalent Engineering Review
Concise selection notes for engineers, buyers, and maintenance teams before sampling or replacement review.
The G12181-005K equivalent page is intended for engineers comparing near-infrared detector options, replacement requirements, package style, sensitivity range, and integration conditions. Sartec Photoelectronics focuses on practical optoelectronic selection support rather than generic catalog matching.
When reviewing G12181-005K equivalent, check the original detector model, spectral response, active area, package footprint, operating circuit, and environmental conditions. This helps confirm whether the device can be used as a realistic equivalent in an OEM instrument or industrial sensing system.
Related technical resources include gas detection modules, TDLAS modules, and technical datasheets. For public background on optical detector terminology, engineers may also reference NIST.
What should engineers compare before selecting G12181-005K equivalent?
Compare spectral response, active area, package type, noise requirements, circuit design, and operating temperature before selecting G12181-005K equivalent.
Is G12181-005K equivalent suitable for replacement evaluation projects?
It can support replacement evaluation, but electrical and mechanical compatibility should be confirmed against the original detector and application circuit.
Can Sartec help review detector alternatives?
Yes. Sartec Photoelectronics can review model numbers, application conditions, and target parameters for optoelectronic replacement projects.
SR-B5-8017-T46W InGaAs photodiode - G12181-005K replacement evaluation
SR-B5-8017-T46W is positioned for compact InGaAs photodiode replacement review and NIR sensing projects. Selection should be based on wavelength, package, active area, and circuit behavior.
Parameters to confirm before RFQ
- Target wavelength and spectral range
- Active area and package dimensions
- Dark current, capacitance, and response speed
- Pinout, bias condition, and PCB footprint
Replacement evaluation boundaries
- A replacement decision should be based on the target circuit and measurement conditions.
- Mechanical compatibility should be checked against the actual package drawing.
- Performance comparison should use the same test conditions where possible.
