N2013 PMTs – Photomultiplier Tubes (Analog to CR10/CR105)

N2013 PMTs -
Photomultiplier Tubes (Analog to CR10/CR105)

N2013 photomultiplier tubes (PMTs) are intended for low-light detection in industrial and scientific instruments. N2013 can be evaluated as an alternative to CR10 and CR105. Compare spectral response, active area, gain at the intended supply voltage, dark current, rise time, base or socket configuration, package dimensions and the voltage-divider circuit before replacement.

Photomultiplier Tube N2013 with spectral response chart showing the wavelength range and sensitivit

Technical Specifications

Technical Specifications – N2013 PMTs
Window materialBorosilicate glass
Photocathode materialBialkali
Dynode structureBox and linear focused
Cathode effective diameter25 mm
Spectral response range290–650 nm
Quantum efficiency peak wavelength380 nm
Luminous sensitivity80 µA/lm
Blue sensitivity11 µA/lmf
Anode blue sensitivity30 A/lmf
Maximum supply voltage1150 V
Gain7 × 106
Maximum dark count rateN2013–1: 140 Hz
 N2013–2: 300 Hz
 N2013–3: 1000 Hz
Anode dark current2 nA
Rise time1.9 ns
Transit time spread3 ns
Operating ambient temperature−30 to +50 °C
Storage temperature−50 to +50 °C

Industrial and Research Applications

•Perfect for use in industrial measurement systems and scientific research where high sensitivity is needed in low-light conditions.
•Medical Imaging: Ideal for imaging systems where precision and sensitivity are crucial.
•Spectroscopy: Suitable for applications that require accurate light signal detection.

N2013 photomultiplier tubes (PMTs) are intended for low-light detection in industrial and scientific instruments. N2013 can be evaluated as an alternative to CR10 and CR105. Compare spectral response, active area, gain at the intended supply voltage, dark current, rise time, base or socket configuration, package dimensions and the voltage-divider circuit before replacement.

Contact Us

For more information or to request a quote, please feel free to contact us directly. We’re happy to assist with product selection and provide additional details about our PMT solutions.

Engineering Review

N2013 PMTs Engineering Review

Concise selection notes for engineers, buyers, and maintenance teams before sampling or replacement review.

01

The N2013 PMTs page is intended for engineers comparing photomultiplier tube options, equivalent models, detection sensitivity, package constraints, and replacement feasibility in industrial or scientific instruments.

02

For N2013 PMTs, review the original tube model, spectral response, gain requirements, socket or base configuration, power supply conditions, dark current expectations, and mechanical envelope before selecting an alternative.

What should engineers compare for N2013 PMTs?

Compare spectral response, gain, package type, socket configuration, operating voltage, and application conditions before selecting N2013 PMTs.

Can Sartec support PMT equivalent selection?

Yes. Sartec Photoelectronics can review original model numbers and target parameters for photomultiplier tube equivalent projects.

Is model matching enough for PMT replacement?

No. The electrical circuit, mechanical fit, sensitivity requirement, and operating environment should also be checked.
